C-type amorphous nuclei
C-section steel is made from a ring or square steel core which, after special fastening, is split by wire cutting or wheel cutting, shaped like a "C".
Description
1. Material: Zhongyue 1K101 iron-based amorphous strip
II. Applicable magnetic flux density: single-phase transformer: 1.30 ~ 1.40 Tesla; three-phase transformer: 1.25 ~ 1.35 Tesla
III. Material density: 7.18g/cm3
IV. Lamination factor: not less than 86%.
Our advantage
Excellent electromagnetic properties
Excellent process capability
Excellent dimensional accuracy
Excellent performance of insulating coating
Widely used
